Info Techniques Sur  Support d'Installation d'Urinoir  (53K)

Info Techniques Sur Support d'Installation d'Urinoir (53K)

PRODUCT IDENTIFICATION
Urinal Installation Frame (53K) for wall hung urinal installation.

APPLICATIONS
- Pre-mounted structure for wall hung urinal mounting with floor and wall fixing.
- Ideal for rehabilitation projects, plasterboard and brick walls.
- Ideal for public spaces.

CARACTÉRISTIQUES DE LA STRUCTURE TECHNIQUE
- Structure tubulaire peinte résistante à la corrosion.

ACCESSORIES EQUIPMENT
- 1 PHED discharge pipe bend.
- 1 Metal ring for outlet bend fixing.
- 1 Rubber ring for outlet bend fixing.
- 2 Screw TCIC M5 x 25
- 1 Protective cover.
- 1 Inlet gasket ø 46
- 2 flanged connections ½”G M-F and screws.
- 2 gaskets for flanged connections.
Accessoires de fixation pour structure murale:
- 4 vis et rondelles Fischer.
- 2 angle metal bracket.

PROPRIÉTÉS
- Régulation en hauteur des supports de plancher réglables (0-200 mm)

OPTIONAL
- Electronic urinal Acier inoxydable control plate
Product Identification and applications
- Urinal control plate
- Ideal for public spaces
Technical Features
- Electronic urinal control plate in Acier inoxydable
- Power supply: 230V, 50Hz
- Electric operation: 30-30V, 50Hz in electrical module
- Electrical consumption: 5VA in discharge
- Principle of operation: Infrared – Proximity
- Range of action: up to 500mm front to the wall
- Water connection G½’’ (ISO 228) in the middle, up or down, connection with rubber seal for 32mm connection pipe
- Water pressure between 0.3 and 10 Bar
- Protection: IP45
- Flush: The flush follows after use. Minimum response time 5s
- Flush time: Réglable from 0 to 6s
- Anti-Vandal system
- Flush performance: at 1 bar, 0.3l/s flow rate; at 2 bar, 0.5l/s flow rate.
Accessories
- 4 Anti-vandal screws.
- 1 Screwdriver for anti-vandal screws.
Timed urinal tap available.
RESISTANCE À LA FATIGUE
Poids statique de 400 kg supporté conforme à la norme NF D 12-208 standard

GARANTIE
Garantie de dix ans (10 ans) Selon les conditions générales de vente, La garantie commence à partir de la date d'achat des produits. Si le produit n'est pas correctement installé, la garantie n'est pas valide.

INFO
Pour plus d'informations, veuillez téléphoner au 01722 415000
